The Probe section will need to be mounted first. It is intended to be positioned with the contacts pointing down. Find a suitable location where water could accumulate if a leak were to occur (eg .along the base board of wall). You will need to determine, if the surface to mount the Probe is smooth or rough/porous. If smooth you can use one piece of the included double sided tape. When using double sided tape apply to clean dry surface. Remove one side of the tape and attach it to the back side of the Probe. Once the mounting surface is ready, remove the other side of the double side tape and position probe so that the metal contacts are pointing down, touching the floor and the back of the Probe (with the double side tape) is up against the wall, base board or mounting plate. Apply pressure to secure the Probe to the surface. If the mounting surface is rough or porous, you will need to use the alternate mounting plate and screws (included). Secure the plate to the desired location with the screws.

Operation Z-Wave Internet:

Including or Pairing the LZ802 to a Z-Wave Controller:

1) Install the batteries. Visual indicator show status (RGB led flash - ready for adding, green flash- device added)

2) Make sure the device is located within direct range of the Z-Wave controller.

3) Follow the instructions of certified controller to include a device from different manufactures in to the Z-Wave network.

4) Once the controller is ready to include your device, triple click the Tamper switch in Shock Sensor.

5) Shock Sensor will be detected and added in the Z-Wave network.

Excluding or Un-Pairing the LZ802 from a Z-Wave Controller:

1) Follow the instructions for your Z-Wave certified controller to exclude a device from the Z-Wave network.

2) Once the controller is ready to Exclude your device, triple click Tamper switch to exclude it from Z-Wave network.

The Shock Sensor is designed to be used in areas where there is a Vibration or glass break detection, etc. When mounted properly it can monitor whether Vibration happened. When Shock is detected, the Sensor will transmit a signal to the Control Center. The Shock Sensor is recommended for use on the alert-only. If there is a shock, Zone will not sound an alarm but a continuous alert until shock has stopped and vibration has dissipated.
