‧ Full HD 1920x1080 at 30fps
‧ The lens is wide angle up to 140 degree
‧ H.264 video compression
‧ Camera with Z-Wave controller/gateway functions integrated
‧ Support Z-Wave devices control, room and scene management
‧ Internal real time clock
‧ WPS
‧ IR cut for days and night usage
‧ Two sensors/lens for day and night separately
‧ 2.4G Hz WiFi with WEP and WPA/WPA2 security support
Software
Z-Wave functions
‧ Z-Wave devices management
‧ Scene designer
‧ Room management
IP Camera functions
‧ Live view mode
‧ Camera control access
‧ Multi-cameras monitoring
‧ Connect up to 8 users simultaneously
‧ Easy setup
‧ Watchdog function to prevent system failure
Playback recording
‧ Time-Lapse recording
‧ SD card recording with 5 seconds of pre-recording
‧ Cloud recording on Dropbox with 5 seconds of pre-recording
‧ NAS recording with 5 seconds of pre-recording
‧ Local recording on your mobile devices with 5 seconds of prerecording
Notifications
‧ Push notifications when an event is detected
DC 5V/1.5A
NETWORK INTERFACE
Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
WIRELESS INTERFACE
2.4 GHz WiFi,
Range: 100 meters line of sight
Full HD
Resolution 1920x1080
IMAGE SENSOR
RGB 2 Mega 1/2.7 inch CMOS
Day and night separate sensors
Automatic exposure control, automatic white balance, automatic gain control, automatic brightness control
Z-Wave MODULE
Sigma Design 500 series module
Tx RF Power : -26 ~ 2 dBm.
Range: 100 meters open site
Radio frequency : 868.42 MHz for Europe/China,
908.42 MHz for United States,
921.42 MHz for Australian/New Zealand,
922 MHz for Japan/Taiwan
LIGHT SENSITIVITY
0.2 Lux ( IR LED off )
0 Lux (with 10 meters IR LED on)
Automatically turn on the IR LED on low light environment
LENS
M12, 2.8 mm, F1.8, viewing angle:140°, fixed iris.
focus range: 50 cm to infinity
BUTTONS
One reset button, to factory default settings
One WPS button for automatic WiFi setup
VIDEO COMPRESSION
H.264, high profile
DIMENSIONS
116 x 57 x 31 mm (H x W x D)
129 g, incl. camera bracket, excl. power adaptor
